New Reduced price! IEC 61188-5-2 Ed. 1.0 b:2003

View larger

IEC 61188-5-2 Ed. 1.0 b:2003

Reference: M00000786

Condition: New product

IEC 61188-5-2 Ed. 1.0 b:2003 Printed boards and printed board assemblies - Design and use - Part 5-2: Attachment (land/joint) considerations - Discrete components

standard by International Electrotechnical Commission, 06/24/2003

More details

In stock

More info

Full Description

Provides information on land pattern geometries used for the surface attachment of discrete electronic components. Provides the appropriate size, shape and tolerances of surface mount land patterns to ensure sufficient area for the appropriate solder fillet, and also allow for inspection, testing and rework of resulting solder joints.

Product Details

Edition: 1.0 Published: 06/24/2003 Number of Pages: 103 File Size: 1 file , 1.3 MB
