New Reduced price! IEC 60933-5 Ed. 1.0 b:1992 View larger

IEC 60933-5 Ed. 1.0 b:1992

M00001754

New product

IEC 60933-5 Ed. 1.0 b:1992 Audio, video and audiovisual systems - Interconnections and matching values - Part 5: Y/C connector for video systems - Electrical matching values and description of the connector

standard by International Electrotechnical Commission, 11/30/1992

More details

In stock

$9.89

-57%

$23.00

More info

Full Description

Applies to the transfer of video signals between two pieces of equipment in an NTSC, PAL or SECAM high-resolution video system, in the form of a Y-signal, consisting of luminance + blanking + sync, and a C-signal, the same as the modulated chrominance signal of the composite video signal. It specifies the signal levels and impedances at the interface and the type of connector to be used.
