The symbols for devices do not indicate types or model numbers of any manufacturer. Theyrepresent the function of the device operated within a CATV system. The symbols permit easyaddition of model or type numbers within or near their outline. If such model or type designationsare used, an explanation of these designations should be placed on a legend sheet for the drawingon which the symbols appear.
Product Details
Published: 01/01/2003 ANSI: ANSI Approved Number of Pages: 15 File Size: 1 file , 210 KB
