Full Description

The purpose of this document is to provide a test method for measuring return loss of "F" Male Connectors with Cable in the frequency range of 5 MHz to 1002 MHz by utilizing the time domain-gating feature of the network analyzer. Male "F" connectors that conform to SCTE 123 2006; Specification for "F" Connector, Male, Feed-Through or SCTE 124 2006; Specification for "F" Connector, Male, Pin Type that are used with 75 ohm flexible RF coaxial cable, such as, but not limited to, ANSI/ SCTE 74; Specification for Braided 75 ohm Flexible RF Coaxial Drop Cable shall be utilized.

Product Details

Published: 01/01/2007 ANSI: ANSI Approved Number of Pages: 9 File Size: 1 file , 210 KB
