Full Description

This specification defines the Network Management requirements to support a Modular Cable Modem TerminationSystem (M-CMTS) for headend components compliant to DOCSIS. The purpose of this document is to definethe management requirements for the M-CMTS architecture that enables an effective operation of the M-CMTScomponents.

The M-CMTS architecture separates the traditional CMTS into two parts. The first part is the downstream physical (PHY) component (known as a DOCSIS EQAM) and the second part consists of the IP networking and DOCSIS MAC functions of the CMTS (known as the M-CMTS Core). This separation of a CMTS into EQAM and M-CMTS Core introduces three new protocol interfaces to DOCSIS-compliant headend systems.DOCSIS Timing Interface (DTI): Provides a frequency reference for M-CMTS Core and DOCSIS EQAM via direct connections to a DTI Server.Downstream External PHY Interface (DEPI): Controls the delivery of DOCSIS frames from the M-CMTS Core to the EQAM devices.Edge Resource Management Interface (ERMI): Provides EQAM devices registration and control to the Edge Resource Management device with the purpose of sharing EQAM resources with video systems such as Video on Demand (VoD).

Product Details

Published: 2017 ANSI: ANSI Approved Number of Pages: 37 File Size: 1 file , 390 KB
