Full Description

Specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of RM-cores and low-profile RM-cores made of ferrite, and the locations of their terminal pins on a 2,54 mm printed wiring grid in relation to the base outlines of the cores. Also specifies the test conditions and clamping forces to be used for inductance measurement.

Product Details

Edition: 1.0 Published: 09/23/2005 Number of Pages: 22 File Size: 1 file , 550 KB
