Full Description

Applies to a.c. and d.c. machines and specifies rules for the identification of winding connection points; marking of winding terminals; direction of rotation; relationship between terminal markings and direction of rotation; terminal marking of auxiliary devices; connection diagrams of machines for common applications. The main change with respect to the previous edition consists of changed terminal markings for d.c. machines.

Product Details

Edition: 3.0 Published: 06/22/2007 Number of Pages: 65 File Size: 1 file , 670 KB
