Full Description

This part of IEC 61788 covers a test method detailing the tensile test procedures to be carried out on Cu/Nb-Ti superconductive composite wires at room temperature. This test is used to measure modulus of elasticity, 0,2 % proof strength of the composite due to yielding of the copper component, and tensile strength. The value for percentage elongation after fracture and the second type of 0,2 % proof strength due to yielding of the Nb-Ti component serves only as a reference (see Clauses A.1 and A.2). The sample covered by this test procedure has a round or rectangular cross-section with an area of 0,15 mm2 to 2 mm2 and a copper to superconductor volume ratio of 1,0 to 8,0 and without the insulating coating. This second edition cancels and replaces the first edition published in 2000. It constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: - the minimum distance between grips was changed from 100 mm to 60 mm; - accuracy and precision statement were converted to uncertainty statements.

Product Details

Edition: 2.0 Published: 01/22/2008 Number of Pages: 21 File Size: 1 file , 890 KB
