Full Description

IEC 60445:2010 applies to the identification and marking of terminals of electrical equipment such as resistors, fuses, relays, contactors, transformers, rotating machines and, wherever applicable, to combinations of such equipment (e.g. assemblies), and also applies to the identification of terminations of certain designated conductors. It also provides general rules for the use of certain colours or alphanumeric notations to identify conductors with the aim of avoiding ambiguity and ensuring safe operation. These conductor colours or alphanumeric notations are intended to be applied in cables or cores, busbars, electrical equipment and installations. This fifth edition is a merged version of IEC 60445 and IEC 60446, and cancels and replaces the fourth edition of IEC 60445, published in 2006, and the fourth edition of IEC 60446, published in 2007. It has the status of a basic safety publication in accordance with IEC Guide 104. This edition includes the following significant technical changes with respect to the previous edition:
- addition of new definitions in Clause 3;
- revision of some clauses to use words from reference IEC standards. These revisions did not change any technical requirements but to clarify the wording;
- addition of Annex B (informative) "List of notes concerning certain countries".

Product Details

Edition: 5.0 Published: 08/27/2010 Number of Pages: 49 File Size: 1 file , 540 KB
