Full Description

IEC 62047-12:2011 specifies a method for bending fatigue testing using resonant vibration of microscale mechanical structures of MEMS (micro-electromechanical systems) and micromachines. This standard applies to vibrating structures ranging in size from 10 m to 1 000 m in the plane direction and from 1 m to 100 m in thickness, and test materials measuring under 1 mm in length, under 1 mm in width, and between 0,1 m and 10 m in thickness. The main structural materials for MEMS, micromachine, etc. have special features, such as typical dimensions of a few microns, material fabrication by deposition, and test piece fabrication by means of non-mechanical machining, including photolithography. The MEMS structures often have higher fundamental resonant frequency and higher strength than macro structures. To evaluate and assure the lifetime of MEMS structures, a fatigue testing method with ultra high cycles (up to 10¹²) loadings needs to be established. The object of the test method is to evaluate the mechanical fatigue properties of microscale materials in a short time by applying high load and high cyclic frequency bending stress using resonant vibration.

Product Details

Edition: 1.0 Published: 09/13/2011 Number of Pages: 59 File Size: 1 file , 660 KB
