IEC 61188-7 Ed. 2.0 en:2017
M00003028
New product
IEC 61188-7 Ed. 2.0 en:2017 Printed boards and printed board assemblies - Design and use - Part 7: Electronic component zero orientation for CAD library construction
standard by International Electrotechnical Commission, 04/10/2017
In stock
More info
Full Description
IEC 61188-7:2017(E) establishes a consistent technique for the description of electronic component orientation, and their land pattern geometries. This facilitates and encourages a common data capture and transfer methodology amongst and between global trading partners.This edition includes the following significant technical changes with respect to the previous edition:
a) Figure 1 has been corrected;
b) the term rectangle has generally been replaced by polygon;
c) level B has been indicated as preferred level for new libraries.
