Full Description

IEC 60947-4-1:2018 is applicable to the following equipment:electromechanical contactors and starters including motor protective switching device (MPSD);actuators of contactor relays; contacts dedicated exclusively to the coil circuit of this contactor or this contactor relay; dedicated accessories (e.g. dedicated wiring, dedicated latch accessory); intended to be connected to distribution circuits, motors circuits and other load circuits, the rated voltage of which does not exceed 1 000 V AC or 1 500 V DC. This fourth edition cancels and replaces the third edition published in 2009 and its Amendment 1:2012. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: Scope structure and exclusions Editorial correction of notes and hanging paragraphs Reference to IEC 62683-1 Motor protective switching device (MPSD) with its requirements Safety aspects related to: General aspects; Limited energy circuits; Electronic circuits; Assessment procedure for electromechanical overload protection used in safety -applications (new Annex L) Introduction of provisions covering the impact of higher locked rotor current to achieve high efficiency class Mention of dedicated wiring accessories Pickup power measurement Alignment to IEC 60947-1:2007, IEC 60947-1:2007/AMD1:2010, and IEC 60947-1:2007/AMD2:2014 Direct current requirements for covering photovoltaic application (new Annex M) Load monitoring indicators (new Annex O) Short-circuit breaking tests of MPSD (new Annex P) Co-ordination under short-circuit conditions between a MPSD and another short-circuit protective device associated in the same circuit (new Annex Q).

Product Details

Edition: 4.0 Published: 10/25/2018 Number of Pages: 371 File Size: 1 file , 3 MB
