Full Description

Specifies the shapes and dimensions of ferrite cores for inductive components (transformers and chokes). Their coil is typically constructed by multi-layer board or is part of the motherboard. Also provides general considerations upon which the design of this range of cores is based.

Product Details

Edition: 1.0 Published: 04/27/2006 Number of Pages: 17 File Size: 1 file , 320 KB
