Full Description

Specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of square cores (RM-cores) made of magnetic oxides, the dimensional limits for wound coil formers to be used with these cores and the locations of their terminal pins on a 2,54 mm printed wiring grid in relation to the base outlines of the cores.

Product Details

Edition: 2.0 Published: 01/01/1983 Number of Pages: 26 File Size: 1 file , 1.1 MB
