Full Description

1 Scope

1.1 This standard specifies the basic formatting structure of the ancillary data space in digital video datastreams in the form of 10 bit words. Application of this standard includes 525 line, 625 line, component orcomposite, and high definition digital television interfaces (750 and 1125 lines) and D-Cinema applicationsthat provide 8-bit or 10-bit data ancillary data space.

1.2 Space available for ancillary data packets is defined in the document specifying the connecting interface.

1.3 Ancillary data packet payload definitions for a specific application shall be according to a SMPTEstandard, a Recommended Practice, an Engineering Guideline or a document generated by anotherorganization. When a payload format is considered a registered format, an application document is requiredand the ancillary packet is identified by a registered data identification word.

Product Details

Published: 09/20/2006 Number of Pages: 14 File Size: 1 file , 180 KB
