Full Description

This standard defines a means of interconnecting digital video equipment with a dual link 1.5 Gb/s SDI (Link Aand Link B), based upon the SMPTE 292 data structure. The source formats for this dual link interface are the1920x1080 picture formats, and digital interface representations as defined in SMPTE 274M and 2048 x 1080operational level 3 format as defined in SMPTE 428-9. The total data rate of the dual link connection is 2.970Gb/s or 2.970/1.001Gb/s. This dual link also supports carriage of the embedded audio, ancillary data and theoptional ID of the stream.

Product Details

Published: 03/02/2009 Number of Pages: 21 File Size: 1 file , 350 KB
