Full Description

This Standard defines the combination of 1.5G-SDI signals, 3G-SDI signals and 6G-SDI signals into a 12G-SDI interface. MODE 1: Carriage of two SMPTE ST 2081-10 6G-SDI signals on a 12G-SDI 10-bit interface as defined in section 7 Single-link 12G-SDI 10-bit Multiplex MODE 2: Carriage of four SMPTE ST 425-1 3G-SDI signals on a 12G-SDI 10-bit interface as defined in section 7 Single-link 12G-SDI 10-bit Multiplex MODE 3: Carriage of eight SMPTE ST 292-1 HD-SDI signals on a 12G-SDI 10-bit interface as defined in section 7 Single-link 12G-SDI 10-bit Multiplex

Product Details

Published: 08/09/2017 Number of Pages: 11 File Size: 1 file , 350 KB
