Full Description

This paper presents a new inspection strategy that effectively compensates the measuring error caused by the requirement of the probe's normal direction approach and workpiece alignment. In this study, the offset surface concept is introduced to eliminate normal directional error. This is based on the fact that when a surface is measured using a ball probe, the center of the probe is always located on another parallel surface (offset surface), offset from the original surface by an amount equal to the probe radius along the surface normal direction. Also, this paper presents the real-time measuring point selection method that can be used to select the position of measuring points during the inspection procedure.

Product Details

Published: 11/01/1999 Number of Pages: 6 File Size: 1 file , 720 KB
