Full Description

THIS PAPER PROPOSES THAT A NEW SYSTEM BE DESIGNED THAT AUTOMATICALLY MEASURES AND ADJUSTS TOOL OFFSETS SPECIFICALLY ON MANUALLY OPERATED CNC TURNING MACHINES. IT COMBINES A RETRACTABLE ARM WITH COMPUTER VISION AND PROCESSOR TECHNOLOGY. IT ELIMINATES 80% OF THE CURRENT TOOL OFFSET ADJUSTMENT TIME. A CAMERA IS MOUNTED ON A RETRACTABLE ARM, ONE IMAGE OF EACH TOOL IS ACQUIRED, AND THE TOOL BEING MEASURED IS HELD IN A TYPICAL INDEXED POSITION AND IS STATIONARY WHEN THE IMAGE IS ACQUIRED. THE SUCCESS OF THIS PROCESS IS BASED ON KEY MECHANICAL TOLERANCES BEING HELD AND SPECIFIC COMPUTER INTERFACES BEING ESTABLISHED.

Product Details

Published: 06/01/1990 Number of Pages: 12 File Size: 1 file , 1 MB
