> >NASA KSC-STD-152-2 Rev. C
New Reduced price! NASA KSC-STD-152-2 Rev. C View larger

NASA KSC-STD-152-2 Rev. C

M00000989

New product

NASA KSC-STD-152-2 Rev. C Graphic Symbols for Drawings. Part 2: Ground Support Equipment, Standard for

standard by National Aeronautics and Space Administration, 05/15/1992

More details

In stock

$21.60

-40%

$36.00

More info

Full Description

This standard establishes the requirements applicable to the graphic symbols used on ground support equipment (GSE) drawings prepared by or for the John F. Kennedy Space Center (KSC), NASA. This standard applies to those symbols used on structural, mechanical, electrical, and electronic drawings used to fabricate, install, or modify GSE and on other operations and maintenance documentation (OMD) drawings required for operation, maintenance, or other use of GSE.

Product Details

Edition: C Published: 05/15/1992 Number of Pages: 79 File Size: 1 file , 1 MB
