ISA 75.08.05-2002 (R2007)
M00002057
New product
ISA 75.08.05-2002 (R2007) Face-to-Face Dimensions for Buttweld-End Globe-Style Control Valves (ANSI Classes 150, 300, 600, 900, 1500, and 2500)
standard by The International Society of Automation, 11/19/2002
In stock
More info
Full Description
Formerly ANSI/ISA 75.15-1994This standard applies to buttweld-end globe-style controls valves, sizes 15 mm (1/2 inch) through 450 mm(18 inches) for Classes 150 through 2500, having top, top and bottom, port, or cage guiding.
The purpose of this standard is to aid users in their piping designs by providing buttweld-end globestylecontrol valve dimensions, without giving special consideration to the equipment manufacturer to beused.
The short-long dimensions provided in Table 1 clarify 2.1 by consolidating the diversity of existingmanufacturers? lengths into two sets of dimensions for each valve size. Before using either the short orlong dimensions, the piping designer should confirm with the selected valve manufacturer which dimensionis correct for the valve(s) being supplied.
